PS Audio – Airlens Network Music Streamer

Design

Whether you stream network music through Roon, Audirvana, JRiver, Tidal Direct, Spotify, your NAS, or any DLNA-compatible server, you will introduce unwanted noise into your sensitive DAC. A USB connection to the computer is by far the noisiest method, followed by a close second via Ethernet or WiFi. What is needed to completely remove this injurious noise is the elimination of any electrical connection between the computer, its network, and your DAC. The PS Audio AirLens has both an input stage and a galvanically isolated reclocking output stage. The two are connected only “through the air.” By using separate power supplies, there are no physical ground or signal connections, ensuring 100% isolation and noise-free delivery of perfect digital audio signals.

Application

Eliminating the noisy USB to-computer connection and instead placing the PS Audio AirLens between your home network via Ethernet or WiFi will change forever the performance of streaming music. Once connected to any DAC, the AirLens interface will bring exceptional transparency, resolution, timbral realism, and wide dynamics to any D to A converter. Noise from any number of sources including your computer, long runs of Ethernet cable, EMI interference through WiFi, the system modem and router, all contribute to increased jitter and a general reduction of fidelity in the system. Connecting your DAC via its coax or I2S inputs completely removes the haze and congestion caused by these noise sources.

Features

• NETWORK INTERFACE FOR STREAMING MUSIC
• PCM UP TO 352KHZ
• DSD TO 256(4X)
• DOP OR NATIVE
• GALVANICALLY ISOLATED INPUT TO OUTPUT
• LOW JITTER RECLOCKER
• DIGITAL LENS OUTPUT
• ELIMINATION OF DIGITAL NOISE AND HASH
• RCA COAX OUTPUT
• I²S OUTPUT
• ROON READY
• DLNA READY
• IMPROVES SOUND QUALITY
• ELIMINATES NETWORK AND WIFI NOISE
• TIDAL CONNECT

Specifications – AirLens

General

• Unit Weight 4.8 lbs [2.2 kg]
• Unit Dimensions 10” x 7” x 1.5” [ 25.4cm x 17.8cm x 3.8cm]
• Shipping Weight 6.8 lbs [3.1 kg]
• Shipping Dimensions 5.8” x 13.6” x 11.6” [14.6 cm x 34.6 cm x 29.4 cm]
• Color Options Black, Silver
• Voltage Options Universal
• Mains Power Input 100-240VAC 50-60Hz
• Power Consumption 5W Typical/10W max
• Accessories Included Power cord
• Input 10/100/1000 Ethernet or 2.4 & 5GHz WIFI
• Audio Outputs 12s, S/PDIF Coax

Featues

Audio Interface
• PCM: Up to 384KHz/32
• Native DSD up to DSD256 (I2S output)
• DoP (DSD over PCM) up to DSD128 (Coax output)
Network Support
• WiFi: IEEE 802.11 b/g/n/ac (2.4 & 5GHz dual band)
• 10/100/1000 Ethernet
WiFi Setup
• WPS
Connectivity
• DLNA 1.5 & UPnP AV 1.0 Digital Media Renderer
• Spotify Connect
• Roon Ready
• TIDAL Connect
• Qobuz (through Roon)
• Dropbox (through Roon)
• MQA
