Specifications
| Inputs | 4 x RCA 1 x XLR Bal. shared with 1 RCA 1 x USB |
| Volume Control | -71dB – 0dB in 1dB steps + Mute |
| Input Sensitivity (IHF 2.83V Out)/Impedance | < 0.05V / > 20KOhm |
| Analogue Outputs | 1 x RCA; 1 x XLR per channel |
| Power Output IHF Dynamic Power | 60 watts per channel at 4 or 8 ohm (stereo mode) 70 watts per channel at 8 ohm (monoblock mode) 120 watts per channel at 2 or 4 ohm (monoblock mode) |
| FTC | 60 watts per channel at 4 or 8 ohm (stereo mode) 70 watts at 8 ohm (monoblock mode) 120 watts per channel at 2 or 4 ohm (monoblock mode) |
| Output impedance | 0.33 ohm, 20 – 20,000 Hz |
| Frequency Response (-1dB) | 10Hz – 30kHz |
| Signal-to-noise ratio “A” weighted | >100 dB |
| Total Harmonic Dist. + Noise (THD+N) | < 0.3% |
| Operational Modes | Pre-Main amplifier mode; Power amplifier mode Monoblock option; |
| Thermionic Electron Valves amplification stage | GE 5670 (NOS) |
| Power Transformer | 380 VA Custom Torroid (Output Stage) 32 VA Custom EI Transformer (Valve Stage) |
| Power consumption | Standby <1 W Power on 25 W at rated output (4R) 250 W |
| Power Supply Capacitance | 44,000uF in total |
| Rated voltage | 100V/120V/230V~ AC 50Hz – 60Hz |
| Mains Fuse | 100V/120V 4A slow blow; 230V 2A slow blow |
| Colour | Silver or Black |
| Dimensions | 17.7 in W by 4.7 in H by 14.6 in D 45 cm W by 12 cm H by 37 cm D 57 cm W by 49 cm H by 25 cm D (shipped) |
| Weight | AM-777 31 lbs / 14 kg Shipped 40 lbs / 18 kg |
