The source is carefully designed with 5 filter levels besides large-sized choke and oil cap. The power supply for the Power and Driver stages is separated to provide absolute stability and stillness for the amplifier.
Thivan’s OPT sound transformer is designed to be very large (total weight of 6kg / unit – similar to those in the high-end 300B Amplifier). This is aimed to optimize sound quality of tube 300B as well as to reach its capacity of 7.5w across the 20Hz – 20 kHz frequency range.
The components used are of high quality and have been thoroughly tested and guaranteed from Thivan Labs to ensure stable and reliable operation.
|Inputs||1 x XRL ; 2 x RCA|
|Speakers||4, 6, 8, 16 Ohms|
|Vacuum tube complement|
|– Input & Driver tube||1 x 12AU7 ; 1 x 6SN7 ; 2x6V6|
|– Power tube||2 x 300B|
|Frequency response||10 Hz – 30 kHz (-1dB) ; 20Hz – 20kHz (-0.1dB)|
|Input Impedance||100 kOhms|
|Power Requirements||220V (possible to set 100 /110/117/240v/50-60Hz by different markets)|
(W x D x H)
|45 x 40 x 26 (cm)|
