Unit Weight: 13.5 lbs [6.1 kg]
Unit Dimensions: 17” x 12” x 3”
Shipping Weight: 17 lbs [7.7 kg]
Shipping Dimensions: 23”x 18” x 9”
Power requirements
Input Power: Model specific 100VAC, 120VAC, or 230VAC 50 or 60Hz
Maximum Power Consumption: 500W
Mains Power Input: IEC C14
Fuses: 100V T250V-2.0AH (5A Slow Blow), 120V T250V-1.6AH (4.5A Slow Blow), 230V T250V-1.0AH (2.5A Slow Blow)
Accessories included: US (NEMA 5-15P) (all versions)
Schuko: (CEE7/7) (230V version)
UK (BS1363) (230V version)
Analogue inputs
RCA: 3 stereo pair
XLR: 1 stereo pair
Digital audio inputs
I2S: 1 PCM (384KHz max), DSD64 DSD128, Compatible with DirectStream Transport SACD handshake for DSD playback
Coax: 2 PCM (192KHz max)
Optical: 1 PCM (96KHz max)
USB: PCM (384KHz max), DSD64 (DoP) DSD128 (DoP)
Format: PCM, DSD
Analogue Audio Outputs
RCA: (Analog Unbalanced) 1 stereo pair
Headphones: One 1/4″ headphone connector front panel
Analogue Performance
Gain: 12dB +/-0.5dB
Maximum output: 20 Vrms
Sensitivity: 5.3Vrms
Input Impedance 47KΩ single ended RCA, 100KΩ Balanced XLR
Output Impedance: 100Ω single ended RCA, 200Ω balanced XLR
Frequency Response: 20Hz – 20KHz +0/- 0.25dB, 10Hz – 100KHz +0.1/-3.0dB
Noise: 20-20KHz <-90dBV S/N Ratio: 1KHz >110dB (max output)
Channel separation: 1KHz >90dB
Input separation: 1KHz >90dB
THD&IM: 1KHz < 0.025%, 20-20KHz < 0.05%
Headphone performance
Output power @1% THD: 300Ω 300mW, 16Ω 3.25W S/N Ratio 1kHz: >95dB (max output)
Noise: <-80dBV
THD & IM 1Vrms out: 300Ω <0.05%, 16Ω <0.06%
Output impedance: <4 Ω
Network Connection
WiFi: 100mbps
Ethernet: 100mbps
Power Amplifier
THD&IM:
1KHz, 1W/4Ω: <0.02%
10-20KHz, 1W/4Ω: <0.02%
10-50KHz, 1W/4Ω: < 0.05% (90kHz BW)
1KHz, 37.5W/4Ω: < 0.01%
Output Power: Both channels driven 120vac mains, 1kHz, 1% THD
8Ω: 100W minimum
4Ω: 200W minimum
2Ω: Stable for musical transients
Features
Volume Control: 0-100 (1/2 and 1dB steps, 80dB total range)
Balance Control: 24dB each direction in 1/2dB steps
Home Theater Mode: Assignable to any analog input, Adjustable (in setup) to any level
Polarity (phase) Control: Digital sources only
Filter Control: 3 selectable digital filters (PCM digital sources only)
Trigger output: (3.5mm 5-15VDC) 2
Remote Control: Yes. Infra Red
