Specifications
- Conductor : 7N Cu D.U.C.C. Stressfreex2 (0.37×18 strands)
- 4N Cu for ground(0.37×18 strands)
- Single Conductor size : 1.93 Sq (AWG 14)
- Insulation material : High molecular Polyolefin Resin (Black & White & Green)
- 1st Inner sleeve : High molecular Polyolefin + tungsten + amorphous + carbon powder
- 2nd Inner sleeve : Polyolefin with Resonance control powder
- Shielding : Copper foil with drain wire
- Outer sleeve : Lead free Polyvinyl Chloride
- Conductor resistance : 7.0mΩ/m
- Cable diameter : 12.6mm
Power plug & IEC connector
- Contact parts : Beryllium copper
- Plating : Silver layered rhodium(Polished before plating)
- Body : Poly Butylene Terephtalate with glass fiber
- Outer case : Polycarbonate
